Common Cable Assembly Grounding Mistakes and How to Fix Them

Introduction
Proper grounding is critical for the safety and performance of cable assemblies in electrical and communication systems. However, grounding errors are surprisingly common and can lead to equipment damage, data loss, or even hazardous electrical shocks. This article explores frequent cable assembly grounding mistakes, their consequences, and actionable solutions to ensure reliability and compliance with industry standards.

​1. Insufficient or Single-Point Grounding

Mistake: Relying on a single grounding point or failing to establish a low-resistance path to the earth. This creates vulnerabilities—if the connection fails, the entire system becomes unsafe.
Consequences: Electrical noise, voltage spikes, and increased risk of short circuits.

Solution:

• Implement a ​multi-point grounding system for redundancy, especially in high-frequency or high-power applications.
• Use ​grounding straps or busbars to create parallel paths, reducing resistance.
• Test grounding resistance with a ​megger (megohmmeter) to ensure it’s below 25 ohms (per NEC standards).

​2. Using Incorrect Grounding Materials

Mistake: Using substandard conductors (e.g., thin wires) or non-corrosion-resistant connectors.
Consequences: Degradation over time, increased resistance, and potential ground failure.

Solution:

• Choose ​copper or tinned copper conductors for optimal conductivity and corrosion resistance.
• Select ​UL-listed grounding clamps and lugs rated for your environment (indoor, outdoor, or industrial).
• Apply anti-oxidation grease to connections in humid or salty environments.

​3. Ignoring Environmental Factors

Mistake: Failing to account for moisture, temperature fluctuations, or chemical exposure.
Consequences: Corrosion, insulation breakdown, and intermittent grounding.

Solution:

• Use ​waterproof grounding kits for outdoor or underground installations.
• Install ​protective conduits in areas exposed to mechanical stress or chemicals.
• Schedule ​bi-annual inspections to check for corrosion or physical damage.

​4. Ground Loops

Mistake: Creating multiple grounding paths with varying potentials, causing circulating currents.
Consequences: Signal interference (hum in audio/video systems), data errors, and accelerated equipment wear.

Solution:

• Design a ​star grounding topology where all cables converge at a single point.
• Use ​isolation transformers or ​optical isolators to break ground loops in sensitive circuits.
• For shielded cables, ground the shield at ​one end only (typically the source) to prevent loop formation.

​5. Improper Shield Termination

Mistake: Leaving cable shields ungrounded or using “pigtail” connections that compromise effectiveness.
Consequences: Electromagnetic interference (EMI) ingress, reduced signal integrity.

Solution:

• Terminate shields with ​360-degree circumferential connectors (e.g., metal gland nuts) for full coverage.
• In noisy environments, ground both ends of the shield but use a ​ground loop isolator to mitigate current flow.
• Avoid twisting shields into loose “pigtails”; instead, use ​crimped or soldered connections.

​6. Neglecting Bonding Requirements

Mistake: Isolated grounding of cable assemblies without bonding them to the main system ground.
Consequences: Potential differences between components, leading to arcing or electrostatic discharge (ESD).

Solution:

• Follow NEC Article 250 guidelines for ​equipment bonding jumpers (EBJs) to unify all grounds.
• Ensure metallic conduits, enclosures, and cable trays are bonded to the grounding electrode system.
